Product Data Sheet

Reliance W95+ Synthetic Bag Filter

APPLICATIONS
The Reliance W95+
Synthetic Bag filter is an
Ultra-fine grade synthetic • ISO16890 ePM1 - 70%
bag filter ideal for use in
ventilation systems where • Synthetic product fitted with aerodynamic
an extremely high dust spacers
spot efficiency is required
for the removal of
• Low replacement cost
atmospheric staining etc.

It may be used as part of a
multi-stage filtration • Robust construction
system and is particularly
suitable where fibre • Available in standard and bespoke sizes
shedding is unacceptable
• Made in Britain
CONSTRUCTION
The pockets are produced
from synthetic micro-fibres
specifically designed for
use in air filtration and
provided with a scrim
support backing bonded to
the exit side of the media.
The pockets are provided
with inflation spacers to Rated Velocity ASHRAE Max Temp Initial Resistance at Rated Final Resistance
Filter Reference 0 Max Humidity
prevent over inflation m/s Efficiency C RV (pa) (pa)
when in use. Each pocket is
fitted with a U profile Reliance W95+ Dependent on 95%+ 60 100%RH 168 250
pocket length
capping strip to ensure no
leakage between pockets. Standard Header Standard Pocket Standard Pocket lengths Standard Header
The sets of pockets are Dimensions (HxW) No.s Depths
retained in a rigid
592x592mm 6,7 or 8
galvanised steel channel,
592x492mm 5 or 6 305mm 381mm 508mm 610mm 762mm 20, 25 or 30mm
which features a specially 592x287mm 3or 4
roll formed safety edge.

Please note: In their continuous search for product improvement Westbury reserve the right to change materials and specifications without prior notice.
Doc

WDATA-RW95-002

Ref: DST-T-V1
