APPLICATIONS
High surface area synthetic

air filtration media • Combination particulate/ gas phase filter
combined with activated
carbon ensures high
degree of odour removal in • M6 to EN779:2012
air conditioning and
industrial processes • Highly efficient modern design using the
without the need for latest materials
additional mid range
filtration. These Filters are • Low energy consumption & long life
ideal for use in commercial
buildings, offices, airports,
hospitals, hotels, • Large filtration surface area consolidated
restaurants etc. into a convenient, simple to use filter.

CONSTRUCTION • Modular size for simple retrofitting older
Westlife Rigicarb model product designs
Filters are manufactured
from a combination of
synthetic and activated
carbon media, close
pleated and bonded into a
rigid V shaped construction
in a durable ABS frame.
These Filters operate Header Media Rated Initial
without carbon shedding Our Ref Height Width Depth size square Capacity Resistance
(mm)
(mm)
(mm)
3
and with a very low air (mm) area (m /hr) (Pa)
resistance. The simple
header frame OC-M6-1-30-20 592 592 290 20 9m2 3400 100
design allows easy
OC-M6-2-30-20 592 287 290 20 4.5m2 1700 100
installation in holding
frames and housings. OC-M6-3-30-20 592 490 290 20 6m2 2400 100
OC-M6-1-30-25 592 592 290 25 9m2 3400 100
OC-M6-2-30-25 592 287 290 25 4.5m2 1700 100
OC-M6-3-30-25 592 490 290 25 6m2 2400 100

Maximum Temperature 60 c Maximum Humidity 95%RH
0
Recommended final resistance: 400Pa

Please note: In their continuous search for product improvement Westbury reserve the right to change materials and specifications without prior notice.
Doc

WDATA-M6RC-001
