APPLICATIONS
Suitable for most gas-
phase filtration • Gas Phase filtration

applications including: • Rechargeable
• Catering
• Suitable for front or side access
• Museums • Wide range of sizes & types
• Archives
• Airport buildings • Suits numerous applications
• Ozone reduction • High adsorption
• VOC removal • Made in Britain
• Mortuary
• Medical
• Pharmaceuticals
• Micro-electronics
• Sewerage Plants
• General odour removal
Rated Airflow Rated Airflow
Typical Panel Size Active carbon Resistance at 0.1 Resistance at
(m3/hr) at 0.1sec (m3/hr) at
(HxWxD Weight sec (pa) 0.2 sec (pa)
dwell 0.2 sec dwell
CONSTRUCTION
The standard loose-fill 592x592x23mm 3.7kg 290 200 145 85
panels are manufactured
throughout in galvanised
mild steel and provided Maximum Operating Temperature 40 c Maximum Humidity 80%RH
o
with rigid internal braces.
The durable cell will easily
accept the forces necessary

to ensure a suitable carbon Application Recommended Grade Ref
Dwell Time *
fill without bellying or
distortion. The panel is Cooking - Spicy, Indian 0.2 < 0.4 Seconds General Purpose Activated Carbon -7C
provided with a removable
Reduction of Kerosene Exhaust fumes 0.1 < 0.2 Seconds General Purpose Activated Carbon -7C
end channel located by
machine screws into Reduction of Ozone 0.1 < 0.2 Seconds General Purpose Activated Carbon -7C
threaded bushes that are Reduction of Diesel Fumes 0.2 Seconds 5% Copper Treated Carbon -9M
simply removed for filter
Reduction of H 2S, SO 2, NO 2, HCl 0.2 Seconds 5% Copper Treated Carbon -9M
replenishment using a
standard cross-head Museum and Archives protection 0.2 Seconds 5% Copper Treated Carbon -9M
screwdriver. Mortuary / formaldehyde reduction 0.4 Seconds Mortuary Grade -MO

Ammonia Neutralisation 0.3 seconds Ammonia Grade -AM

Note * Dwell time is the contact time that the air is within the carbon matrix

Please note: In their continuous search for product improvement Westbury reserve the right to change materials and specifications without prior notice.
