Product Data Sheet

Hepa Filter Holding Frames

APPLICATIONS

Suitable for numerous • Adaptable modular design
applications where front
access to Hepa filters is
required. • Location dimples to ensure correct
fitting
CONSTRUCTION

Manufactured in either • Pre-drilled for easy assembly
Galvanised or Stainless
Steel as standard, the • Robust construction
frames are fully welded to
ensure robust construction
and rigidity in use. • Available in a range of sizes
Once installed into a
housing or duct, Hepa
filters can be simply
clamped to the internal
flange, using the four
corner mounted clamps, to
provide an airtight seal.
Unit

Construction External Dimensions HxWxD Filter Dimensions HxWxD Weight

Galvanised steel 626x626x340mm 610x610x292mm 12.5kg

Galvanised steel 321x626x340mm 305x610x292mm 10.0kg
Galvanised steel 610x610x340mm 595x595x292mm 12.3kg
Galvanised steel 305x610x340mm 289x595x292mm 9.9kg
Stainless steel 626x626x340mm 610x610x292mm 12.5kg
Stainless steel 321x626x340mm 305x610x292mm 10.0kg
Stainless steel 610x610x340mm 595x595x292mm 12.3kg
Stainless steel 305x610x340mm 289x595x292mm 9.9kg

This product can be manufactured to bespoke dimensions – please contact our
offices for further details.

Please note: In their continuous search for product improvement Westbury reserve the right to change materials and specifications without prior notice.
Doc

WDATA-HFFWF--001

Ref: DST-T-V1
